Traxsmart GPS Tracking

Unrivaled Reliability, Ultimate Control. Track Smarter, Drive Safer

Sentry Series (KAVACH)

SKU: KAVACH

~~₹6999~~₹5999

High-performance asset tracker with long battery life, real-time location tracking, and SOS alerts for reliable protection of vehicles and valuable assets.

Buy Now

Estimated delivery: June 21 - June 28

Free shipping & returns: On all orders over $50

Guarantee safe and secure checkout

Unrivaled Reliability, Ultimate Control. Track Smarter, Drive Safer.

Sentry Series (KAVACH).

Certified for AIS140 and BIS16833, the TSindia140 is a next-generation GPS tracker engineered for total fleet control, regulatory compliance, and real-time visibility. Designed for vehicles of all kinds — from commercial fleets to heavy-duty machines — it delivers advanced features, remote management, and data-driven insights to maximize operational efficiency.

AIS140 & BIS IS16833 Certified

Remote Immobilization & Real-Time Alerts

Advanced Sensor Integration

Fast & Accurate GPS Tracking

Built Rugged with IP65 Protection

Discover more

Certification

AIS140 & BIS IS16833 Approved

Protocol Support

Government-mandated VLT and emergency button protocols

Supported Alerts

SOS button press, Over speeding, Harsh braking, Harsh acceleration, Ignition ON/OFF, Tow detection, Power cut, GPS signal lost, Emergency alert, Geofence entry/exit, Device health check

SOS Button

Included for emergency response (AIS140 requirement)

Remote Immobilization

Vehicle ignition cut-off supported for theft or misuse control

GPS Tracking

Live location updates, 30s cold start, geo-fencing enabled

Power Backup

1000mAh internal battery for power-loss protection

Sensor Support

Fuel, door, AC, temperature, load sensors supported via I/Os

OTA Updates

Over-the-air configuration and firmware upgrade support

Connectivity

4G fallback 2G

Power Supply

9–90 V DC

Cellular

LTE Cat-1 (FDD): Bands B1/B3/B5/B8/B40

LTE Data Rate

Uplink: up to 5 Mbps, Downlink: up to 10 Mbps

GNSS Sensitivity

Acquisition: -147 dBm, Tracking: -163 dBm, Reacquisition: -156 dBm

GNSS Acquisition

TTFF @ -130 dBm, Cold Start: 30s, Warm Start: 25s, Hot Start: 2s

GNSS Receiving Bands

GPS L1, GLONASS L1, Galileo E1, IRNSS L5

Horizontal Position Accuracy

< 1.8 m CEP

Communication

TCP/IP, HTTP, FTP, SMS

Accelerometer

6 Axis Motion Sensing

Internal Battery

3.7 V Li-Poly, 1000 mAh

Antenna

High Gain Onboard Antennas for LTE & GNSS

LEDs

Three LEDs for Power, GNSS, LTE and debug status indication

Device Working Mode

Active mode, Hault mode & Sleep mode

Memory

Storage for 40000+ packets

Housing

Dust & Water Proof (IP65)

SIM Type

Dual profile eSIM / Nano SIM

Operating Temperature

-20°C to 85°C

Storage Temperature

-40°C to 85°C

Protections

Reverse Polarity, Overvoltage, Short Circuit, Surge, Load Dump

Certification

AIS-140 Compliant (ARAI), RoHS Compliant

Current Consumption

Active Mode: 60–120 mA, Sleep Mode: < 20 mA

Software Features

FOTA, Odometer, Geo-fencing, Turn Detection, GPS Drift Control, Driving Behavior

Connector

15 Pins

Connectivity

Ignition, Panic Button, Digital Input, Digital Output, Analog Input, RS232

Wire Harness

4 Sqmm (7–36) SWG High Quality Flexible Wire, Current Rating: 1.5 Amps Max, Length: 1 mtr

Packaging information

TSindia140 GPS Device

Wiring Harness

External GNSS & GSM Antennas (if applicable)

SOS Button (AIS140 variant)

Installation Guide

Shipping Information

Free shipping on orders over ₹10,000

Standard delivery: 3–7 business days

Express delivery available at checkout

International shipping via DHL/FedEx

Secure, pre-tested and sealed packaging

Bulk Orders

We support large-scale deployment for fleet operators, system integrators, OEMs, and government projects. Special pricing, custom branding, and integration support available for orders of 50 units or more. Reach out to our sales team for volume discounts and tailored logistics.

For custom labeling, pre-configuration, or white-label requests, contact our enterprise sales desk. Contact Us
