Unrivaled Reliability, Ultimate Control. Track Smarter, Drive Safer.

Sentry Series (TSINDIA140)

SKU: TSINDIA140
₹5599₹4500

TSINDIA140 compliant vehicle tracker with real-time GPS tracking, emergency alerts, and secure connectivity for improved fleet safety and regulatory compliance.

Buy Now
Estimated delivery: June 21 - June 28
Free shipping & returns: On all orders over $50
Guarantee safe and secure checkout
Unrivaled Reliability, Ultimate Control. Track Smarter, Drive Safer.

The TSindia140: Advanced Tech for Modern Fleets.

Certified for AIS140 and BIS16833, the TSindia140 is a next-generation GPS tracker engineered for total fleet control, regulatory compliance, and real-time visibility. Designed for vehicles of all kinds — from commercial fleets to heavy-duty machines — it delivers advanced features, remote management, and data-driven insights to maximize operational efficiency.

AIS140 & BIS IS16833 Certified
Remote Immobilization & Real-Time Alerts
Advanced Sensor Integration
Fast & Accurate GPS Tracking
Built Rugged with IP65 Protection
Discover more
Certification
AIS140 & BIS IS16833 Approved
Protocol Support
Government-mandated VLT and emergency button protocols
Supported Alerts
SOS button press, Over speeding, Harsh braking, Harsh acceleration, Ignition ON/OFF, Tow detection, Power cut, GPS signal lost, Emergency alert, Geofence entry/exit, Device health check
SOS Button
Included for emergency response (AIS140 requirement)
Remote Immobilization
Vehicle ignition cut-off supported for theft or misuse control
GPS Tracking
Live location updates, 30s cold start, geo-fencing enabled
Power Backup
1000mAh internal battery for power-loss protection
Sensor Support
Fuel, door, AC, temperature, load sensors supported via I/Os
OTA Updates
Over-the-air configuration and firmware upgrade support
Connectivity
2G
Power Supply
9–90 V DC
Cellular
Quad Band 900/1800/850/1900
GPRS Data
GPRS class 12: max. 85.6 kbps (downlink/uplink)
GNSS Sensitivity
Acquisition: -147 dBm, Tracking: -163 dBm, Reacquisition: -156 dBm
GNSS Acquisition
TTFF @ -130 dBm, Cold Start: 32s, Warm Start: 25s, Hot Start: 2s
GNSS Receiving Bands
GPS L1/Galileo E1 C/A: 1575.42 MHz, IRNSS L5 C/A: 1176.45 MHz, GLONASS L1 C/A: 1602.5625 MHz
Horizontal Position Accuracy
< 1.8 m CEP
Communication
TCP/IP, HTTP (For CDAC), FTP, SMS
Accelerometer
6 Axis Motion Sensing
Internal Battery
3.7 V Li-Poly, 1000 mAh
Antenna
High Gain Onboard Antennas for GSM & GNSS
LEDs
Three LEDs for Power, GPS, GSM and debug status indication
Device Working Mode
Active mode & Sleep mode
Memory
Storage for 40000+ packets
Housing
Dust & Water Proof (IP65)
SIM Type
Dual profile eSIM / Plastic SIM
Operating Temperature
-20°C to 85°C
Storage Temperature
-40°C to 85°C
Protections
Reverse Polarity, Overvoltage, Short Circuit, Surge, Load Dump
Certification
AIS-140 Compliant (ARAI), RoHS Compliant
Current Consumption
Active Mode: 50–90 mA, Sleep Mode: < 20 mA
Software Features
FOTA, Odometer, Turn Detection, GPS Drift Control, Driving Behavior
Connector
15 Pins
Connectivity
Ignition, Panic Button, Digital Input, Digital Output, Analog Input, RS232
Wire Harness
4 Sqmm (7–36) SWG High Quality Flexible Wire, Current Rating: 1.5 Amps Max, Length: 1 mtr
Packaging information
TSindia140 GPS Device
Wiring Harness
External GNSS & GSM Antennas (if applicable)
SOS Button (AIS140 variant)
Installation Guide
Shipping Information
Free shipping on orders over ₹10,000
Standard delivery: 3–7 business days
Express delivery available at checkout
International shipping via DHL/FedEx
Secure, pre-tested and sealed packaging
Bulk Orders

We support large-scale deployment for fleet operators, system integrators, OEMs, and government projects. Special pricing, custom branding, and integration support available for orders of 50 units or more. Reach out to our sales team for volume discounts and tailored logistics.

For custom labeling, pre-configuration, or white-label requests, contact our enterprise sales desk. Contact Us
